Polaris RZR XP 1000 4 Seater Tender Spring Kit (Walker Evans Shocks)

A smoother ride for your four-seat RZR.

The All Thingz UTV Polaris RZR XP 1000 four-seat tender spring kit for Walker Evans shocks is designed to reduce harsh impacts and support a more comfortable ride on uneven trails. It replaces the tender springs on your existing shock assemblies while retaining the main springs.

Choose a full set, a front pair, or a rear pair for the work you are doing. Provide your model year, accessories, and typical load when ordering.

What this kit offers

• Trail comfort: Tender springs designed to take the edge off harsh terrain.
• Ride-height adjustment: Use the model-specific setup guidance below after installation.
• Flexible kit options: Replace all four tender springs or select the axle pair you need. Replacement shock assemblies are not included.

Vehicle fitment

Before ordering: Confirm Walker Evans shocks are installed and double-check your selected spring color. This kit is for the earlier XP 1000 body style; the redesigned 2024+ XP 1000 uses a separate kit.

What's included

Select an available raw or powder-coated finish. Powder coating is completed in-house at All Thingz UTV; some colors carry an additional charge.

Tender springs or a dual-rate kit?

Choose this tender kit to retain your existing main springs. To replace upper and lower springs, compare the XP 1000 four-seat Walker Evans dual-rate kit. Its full-kit option includes four front and four rear springs; a lowers-only option is also listed. Check that listing's fitment and selected option before ordering.

Installation overview and setup

Use the Polaris service procedure for your exact model year and installed shock package, together with the instructions for this All Thingz UTV spring kit. Safely support the vehicle and release spring tension with appropriate equipment before removing spring retainers. Use your model's fastener torque specifications during reassembly.

Polaris's suspension diagrams identify where factory preload measurements are taken. Those shock measurements are separate from ground clearance. Factory spring preload dimensions must not be copied directly onto a different spring kit.

All Thingz UTV ride-height baseline

The following figures are All Thingz UTV setup baselines for this RZR XP 1000 spring-kit application, organized by tire size. They are not Polaris factory specifications or independently verified measurements for every vehicle configuration.

Measurement reference: Ground to the underside of the skid plate, with the vehicle on level ground and the suspension settled after moving the vehicle forward and backward. Use consistent reference points when comparing measurements. These starting references do not guarantee a finished height; tire dimensions, pressure, passengers, accessories, and suspension setup affect the result. Listed tire sizes do not confirm tire fitment.

Polaris factory ground-clearance reference

The following figures are published for the 2023 Polaris RZR XP 1000 in its factory configuration. They are factory specifications, not front/rear loaded ride-height targets for this aftermarket tender spring kit. Other model years and configurations must be checked in their own manual.

Polaris 2023 RZR XP 1000 owner's manual — specifications and suspension settings

Follow the installation procedure and adjustment limits for your exact model and shock package. Contact All Thingz UTV for help with your spring-kit setup if your vehicle configuration requires additional guidance.

Spring installation video

General installation overview: Steps, hardware, and adjustments may differ by model year and shock package. Follow the service procedure for your machine and All Thingz UTV settings for this kit.

Find the kit for your RZR configuration

These are alternatives, not required add-ons. Check model year, seat count, and shock package on the linked listing.

• XP 1000 four-seat tender kit for Fox shocks
• XP 1000 two-seat tender kit for Walker Evans shocks
• 2024+ XP 1000 four-seat Walker Evans tender kit — redesigned body style
